Specification
Amplifier Section
|
|
PMPO
|
1000 W
|
RMS Power output
|
|
THD 10% both channel driven
|
|
100 Hz (Low channel)
|
25 W per channel (6Ω )
|
1 kHz (High channel)
|
25 W per channel (6Ω )
|
Total Bi-Amp power
|
50 W per channel
|
Input sensitivity
|
|
AUX
|
250 mV
|
MIC
|
0.7 mV
|
Input impedance
|
|
AUX
|
19.8 kΩ
|
MIC
|
680Ω
|
|
|
FM Tuner Section
|
|
Frequency range
|
87.50-108.00 MHz (50 kHz steps)
|
Sensitivity
|
2.5μ V (IHF)
|
S/ N 26 dB
|
2.2μ V
|
Antenna terminal(s)
|
75Ω (unbalanced)
|
|
|
AM Tuner Section
|
|
Frequency range
|
522-1629 kHz (9 kHz steps)
|
|
520-1630 kHz (10 kHz steps)
|
Sensitivity
|
|
S/ N 20 dB (at 999 kHz)
|
560μ V/ m
|
|
|
Cassette Deck Section
|
|
Track system
|
4 track, 2 channel
|
Heads
|
|
Record/ playback
|
Solid permalloy head
|
Erasure
|
Double gap ferrite head
|
Motor
|
DC servo motor
|
Recording system
|
AC bias 100 kHz
|
Erasing system
|
AC erase 100 kHz
|
Tape speed
|
4.8 cm/ s
|
Frequency response (+ 3 dB, -6 dB at Deck Out)
|
Normal (type I)
|
35 Hz - 14 kHz
|
S/ N
|
50 dB (A weighted)
|
Wow and flutter
|
0.18% (WRMS)
|
Fast forward and rewind time
|
Approx. 120 seconds with C-60 cassette tape
|
|
|
CD Section
|
|
Sampling frequency
|
44.1 kHz
|
Decoding
|
16 bit linear
|
Beam source/ Wavelength
|
Semiconductor laser/ 780 nm
|
Number of channels
|
Stereo
|
Frequency response
|
20 Hz - 20 kHz (+ 1, -2 dB)
|
Wow and flutter
|
Below measurable limit
|
Digital filter
|
8 fs
|
D/ A converter
|
MASH (1 bit DAC)
|
Video CD
|
|
Video data
|
Based on MPEG 1
|
Audio data
|
Based on MPEG 1/ Layer 2
|
Video output
|
|
Video format
|
NTSC/ PAL
|
Output voltage
|
1 Vp-p, 75Ω
|
Physical format
|
Based on CD-ROM format
|
MP3
|
|
MP3 decoder
|
MPEG 1 Layer 2/ Layer 3
|
Bit rate
|
32 kbps - 320 kbps (Variable bit rate)
|
Sampling frequency
|
32 kHz, 44.1 kHz, 48 kHz
|
MP3 decoder
|
MPEG 2 Layer 2/ Layer 3
|
Bit rate
|
8 kbps - 160 kbps
|
Sampling frequency
|
16 kHz, 22.05 kHz, 24 kHz
|
MP3 decoder
|
MPEG 2.5 Layer 3
|
Bit rate
|
8 kbps - 160 kbps
|
Sampling frequency
|
8 kHz, 11.025 kHz, 12 kHz
|
WMA
|
|
WMA decoder
|
Vesion 8
|
Bit rate
|
20 kbps - 192 kbps
|
Sampling frequency
|
32 kHz, 44.1 kHz, 48 kHz
|
|
|
General
|
|
Power supply
|
AC 110 V/ 127 V/ 220-230 V/ 240V, 50/ 60Hz
|
Power consumption
|
110 W
|
Standby
|
Approx. 0.99 W
|
Dimensions (W x H x D)
|
179 x 241 x 375 mm
|
Mass
|
5.6 kg
|
|
|
System: SC-PM137 (GC)
|
Music Center: SA-PM137 (GC)
|
|
Speaker: SB-PM137 (GC)
|
Notes:
-
Specifications are subject to change without notice.
Mass and dimensions are approximate.
-
Total harmonic distortion is measured by the digital spectrum analyzer.
|
